Edge gap control
High-performance light barriers for edge gap control in the kiln
Our solution is a new type of infrared light barrier. This new light barrier impresses with its range of up to 600 m, its very high penetration and, above all, its simple installation and alignment.
Compared to previous solutions, it is aligned in "seconds", even over long distances.
In the meantime, the light barrier has proven its worth many times over and has become the new standard solution for the task of edge gap control.
We would be happy to advise you on the possible applications of the high-performance light barrier in your kiln and make you an offer.
Compared to previous solutions, it is aligned in "seconds", even over long distances.
In the meantime, the light barrier has proven its worth many times over and has become the new standard solution for the task of edge gap control.
We would be happy to advise you on the possible applications of the high-performance light barrier in your kiln and make you an offer.
Register falling objects
With the new generation of edge gap control: save time and money
This new infrared light barrier offers you maximum safety and reliability.
Technical data:
- Designation: transmitter/receiver: infrared light barrier
- Light used: infrared, 850 nm, insensitive to extraneous light
- Range: 600 m
- Fields of application:Wherever strong penetration, dirt resistance, range and easy handling are required.
- Power supply: 24 VDC
- Outputs: pnp, short-circuit proof
- Design :M30 metal housing, protection class IP 67
Brochure Flyer High-performance light barrier
